This AD was prompted by a report of a wing separation caused by fatigue cracking in a visually inaccessible area of the lower main wing spar cap. Piper has issued two Mandatory Service Letters addressing potential cracks in bolt holes, fatigue cracking and corrosion damage in the lower main wing spar on the Piper PA-28 and PA-32.
Nextant Aerospace NDT Eddy-Current Inspection
Affected Models and Serial Numbers
Piper PA-28
| MODEL | SERIAL NUMBERS |
|---|---|
| PA-28-151 | All serial numbers |
| PA-28-161 | All serial numbers except 2842006 |
| PA-28-181 | All serial numbers |
| PA-28-235 | All serial numbers |
| PA-28R-180 | All serial numbers |
| PA-28R-200 | All serial numbers except 28R-7235151 |
| PA-28R-201 | All serial numbers except 2844029, 2844030, 2844081, 2844125, 2844136, 2844147 through 2844151, 28R-7737078, 28R-7737142, 28R-7837108, 28R-7837125, and 28R-7837257 |
| PA-28R-201T | All serial numbers |
| PA-28RT-201 | All serial numbers |
| PA-28RT-201T | All serial numbers |
Piper PA-32
| MODEL | SERIAL NUMBERS |
|---|---|
| PA-32-260 | All serial numbers |
| PA-32-300 | All serial numbers |
| PA-32R-300 | All serial numbers |
| PA-32RT-300 | All serial numbers except 32R-7985004 |
| PA-32RT-300T | All serial numbers |
